S110-24T2SR

Model: S110-24T2SR

Maximum physical ports: 26 (26 GE; 26 FE)

Long-term operating temperature: 0 C to 40 C at 0-1800 m altitude

Long-term operating relative humidity: 5% to 95% RH, non-condensing

Storage temperature: -40 C to +70 C

Long-term operating altitude: 0-5000 m

Storage altitude: 0-5000 m

Above 1800 m the maximum operating temperature drops 1 C for every 220 m of altitude gain, up to 5000 m

Chassis height: 1 U

Installation type: Rack mounting, desk mounting, wall mounting

Dimensions without packaging (H x W x D): basic 43.6 mm x 442.0 mm x 160.0 mm; maximum 43.6 mm x 442.0 mm x 167.0 mm

Dimensions with packaging (H x W x D): 90.0 mm x 550.0 mm x 260.0 mm

Weight without packaging: 1.8 kg (3.97 lb)

Weight with packaging: 2.3 kg (5.07 lb)

Switching capacity: 52 Gbit/s

Packet forwarding rate: 38.69 Mpps

Heat dissipation: natural

Power supply mode: AC built-in

Rated input: 100-240 V AC; 50/60 Hz

Input voltage range: 90-264 V AC; 45-65 Hz

Maximum input current: 0.8 A

Static power consumption: 5 W

Typical power consumption: 16 W

Maximum power consumption: 17 W

100% load power consumption: 16 W

Service port surge protection: +/-1 kV common mode

Power supply surge protection: +/-6 kV differential mode; +/-6 kV common mode

24 x 10/100/1000BASE-T ports; 2 x GE SFP ports

Certifications: EMC, safety, and manufacturing certifications
